Waterproof 20A 12V/24V MPPT solar charge controller with Bluetooth connectivity for caravans, motorhomes, campervans, boat, yacht and marine applications
Waterproof 20A 12V/24V MPPT solar charge controller with Bluetooth connectivity for caravans, motorhomes, campervans, boat, yacht and marine applications
SKU:LUX2024WP-BT
Our stock levels are dynamic and can change frequently. If a product appears to be in stock, it may have already sold out. Please contact us if you have any questions about availability. Thank you for your understanding.
Couldn't load pickup availability
LUX2024WP-BT MPPT Controller
20A 12V/24V Waterproof IP67 with Bluetooth
The LUX2024WP-BT is a professional-grade, fully sealed MPPT solar charge controller designed for the harshest environments. Engineered for reliability in marine, caravan, and off-grid applications, it utilizes advanced Maximum Power Point Tracking technology to extract up to 30% more power compared to standard PWM controllers.
Key Features
- ✔ MPPT Efficiency: Tracking >99.9% / Conversion 97.5%
- ✔ Bluetooth Built-in: Monitor via SolarLife App
- ✔ Multi-Battery Support: Lithium, AGM, Gel, & Liquid
- ✔ IP67 Waterproof: Completely sealed for marine use
- ✔ Auto Recognition: Supports both 12V and 24V
Technical Specs
| Model | LUX2024WP-BT |
| Max Charge Current | 20A |
| System Voltage | 12V / 24V Auto |
| Max PV Power | 260W (12V) / 520W (24V) |
| Max PV Voltage | 55V |
| Self-Consumption | <10mA |
| Dimensions | 145 x 85.8 x 30 mm |
Compatibility / Fitment Guide
| System Type | Application | Notes |
|---|---|---|
| Marine / Boat | Yachts & Canal Boats | Perfect for humid/wet lockers. |
| Automotive | Caravans & Motorhomes | Compatible with LiFePO4 batteries. |
| Off-Grid | Remote Solar Stations | Outdoor installation ready. |
OEM Cross Reference
| Part Number | LUX2024WP-BT |
| Series | LUX WP Series MPPT |
| Related Codes | LUX1012WP-BT, LUX1524WP-BT |
Installation Guide
- Connect the Battery first (mandatory for system recognition).
- Connect the Solar Panel (ensure voltage is below 55V).
- Connect the Load terminals (optional).
- Download the "SolarLife BT" app from the App Store or Google Play to configure battery parameters.
Questions & Answers
Is this a genuine original part?
This is a premium Solarika specification part, manufactured to meet the exact LUX WP series MPPT standards for high-end marine and outdoor solar performance.
How do I know if it is compatible?
If your solar array is 12V or 24V and produces less than 20 Amps, this controller is a perfect fit. Ensure your PV Voc (open circuit voltage) does not exceed 55V.
What app is used for the Bluetooth monitoring?
This controller uses the "SolarLife BT" or "SolarLife" mobile app, available for both iOS and Android. It allows you to view charge rates, battery voltage, and historical data.
Note: Solarika.co.uk recommends using appropriate fuses between the battery and the controller for safety. Please verify your system parameters before installation.
