Solarika LUX1524WP-BT MPPT Controller

15A Waterproof 12V/24V MPPT with Bluetooth

The Solarika LUX1524WP-BT is a professional-grade MPPT (Maximum Power Point Tracking) solar charge controller designed for harsh environments. With an IP67 waterproof rating and a fully sealed aluminium housing, it is the ideal choice for marine applications, off-grid lighting, and leisure vehicles where moisture or dust exposure is a concern. The integrated Bluetooth module allows for seamless wireless monitoring and parameter adjustment directly from your smartphone.

RELIABILITY: Built with advanced MPPT technology boasting a tracking efficiency of over 99.9% and a peak conversion efficiency of 97.5%.

Key Features

  • ✔ Integrated Bluetooth: Built-in module for app connectivity
  • ✔ IP67 Waterproof: Fully sealed for marine/outdoor use
  • ✔ Multi-Battery Support: AGM, Gel, Liquid, and Lithium
  • ✔ 4-Stage Charging: MPPT, Boost, Equalize, and Float
  • ✔ Advanced Protection: Overcharge, discharge, and short circuit

Technical Specs

Max Charging Current 15A
System Voltage 12V / 24V Auto
Max PV Input Power 200W (12V) / 400W (24V)
Max PV Voltage (Voc) 55V
Waterproof Rating IP67
Self-Consumption <12mA
Dimensions 145 x 85.8 x 30 mm

Compatibility / Fitment Guide

Make/System Model/Application Notes
Marine / Boats Yachts, Narrowboats, Ribs Perfect for high-humidity salt environments.
Leisure Vehicles Campervans, Caravans, Motorhomes Compact size fits in tight electrical cabinets.
Off-Grid Systems Garden Lighting, Solar Gates, Sheds IP67 rating allows for exterior mounting if required.

OEM Cross Reference

Solarika Reference LUX1524WP-BT
Photonic Universe LUX1524WP-BT / LUX1524WP
Common Alternates 15A Waterproof MPPT Bluetooth Solar Regulator

Installation Guide

Sequence: Always connect the Battery first to allow the controller to auto-detect system voltage (12V or 24V). Then connect the Solar Panel. Wire Sizing: Recommended 4.0mm² cable for the 15A output. Professional installation is recommended to ensure correct fuse placement on the battery line.

Questions & Answers

Is this a genuine original part?

This is a premium Solarika LUX series component, manufactured to the highest MPPT standards for efficiency and durability in wet environments.

How do I know if it is compatible?

If you have a 12V or 24V battery bank and your solar panel's Open Circuit Voltage (Voc) is under 55V, this controller is a perfect match.

Can I use this with Lithium (LiFePO4) batteries?

Yes, the LUX1524WP-BT supports Lithium battery profiles which can be fully configured via the Bluetooth mobile app.

Note: Visit Solarika.co.uk for further technical support. Please verify your system voltage before final connection.
