Victron SmartSolar MPPT 150/60 60A solar charge controller for solar panels up to 860W (12V) / 1720W (24V) / 2580W (36V) / 3440W (48V) up to 150V (Bluetooth inbuilt)
Victron SmartSolar MPPT 150/60 60A solar charge controller for solar panels up to 860W (12V) / 1720W (24V) / 2580W (36V) / 3440W (48V) up to 150V (Bluetooth inbuilt)
SKU:VSSM150-60
Our stock levels are dynamic and can change frequently. If a product appears to be in stock, it may have already sold out. Please contact us if you have any questions about availability. Thank you for your understanding.
Couldn't load pickup availability
Victron SmartSolar MPPT 150/60 - VSSM150-60
60A High-Efficiency Solar Charge Controller with Bluetooth
The Victron SmartSolar MPPT 150/60 (VSSM150-60) is a professional-grade solar charge controller designed to maximize energy harvest from your solar array. Featuring ultra-fast Maximum Power Point Tracking (MPPT), it optimizes energy yield by up to 30% compared to PWM controllers, especially in clouded or changing weather conditions. This unit is ideal for large-scale off-grid systems, marine environments, and heavy-duty motorhome setups.
Key Features
- ✔ Ultra-fast MPPT: Enhances energy harvest by up to 10% vs slower MPPTs.
- ✔ Inbuilt Bluetooth: Wireless system monitoring and programming.
- ✔ Multi-Voltage Support: Automatic 12V / 24V / 48V detection (36V via software).
- ✔ Programmable Relay: Can be set for alarms, generator start, or load shedding.
- ✔ Battery Compatibility: Supports AGM, Gel, Lead-Acid, and Lithium (LiFePO4).
Technical Specs
| Max PV Voltage: | 150V |
| Rated Charge Current: | 60A |
| Max PV Power (12V): | 860W |
| Max PV Power (48V): | 3440W |
| Peak Efficiency: | 98% |
| Self-Consumption: | <35mA @ 12V |
| Enclosure Rating: | IP43 / IP22 |
| Dimensions: | 185 x 250 x 95 mm |
Compatibility / Fitment Guide
| System Type | Application | Notes |
|---|---|---|
| Off-Grid Solar | Cabins / Workshops | Supports large 48V arrays. |
| Marine | Yachts / Barges | Resin encapsulated electronics. |
| Leisure Vehicles | Large Motorhomes | Bluetooth monitoring via VictronConnect. |
OEM Cross Reference
| Victron MPN | SCC115060210 |
| Photonic Universe SKU | VSSM150-60 |
| EAN | 8719076040170 |
Installation Guide
Installation is straightforward via the 2 pairs of terminals (Battery and PV). It is recommended to use cables up to 35mm² to ensure minimal voltage drop. Always connect the battery first to allow the controller to detect the system voltage (12/24/48V) before connecting the solar panels. Full configuration can be completed via the VictronConnect app.
Questions & Answers
Is this a genuine original part?
Yes, this is a genuine Victron Energy SmartSolar MPPT controller, distributed by Solarika. It features the full 5-year manufacturer warranty.
How do I know if it is compatible?
Ensure your battery bank is 12V, 24V, 36V, or 48V. Your total solar panel open-circuit voltage (Voc) must not exceed 150V under any conditions.
Does it work with Lithium batteries?
Yes, this controller has a dedicated Lithium charging profile and can be fully customized for specific Lithium chemistries via the Bluetooth app.
Note: Please verify your maximum solar array voltage against the 150V limit before purchasing. For technical support, contact Solarika.co.uk.
