ADVANCED TECHNOLOGY: Features a high PV input voltage range (up to 500VDC) and a battery-independent design, allowing the system to operate directly from solar power during daylight hours.

Key Features

• ✔ Pure Sine Wave: Clean power for sensitive electronics.
• ✔ Built-in 80A MPPT: Maximizes solar harvest efficiency.
• ✔ Battery Independent: Run loads directly from PV panels.
• ✔ High PV Input: Supports array voltages up to 500VDC.
• ✔ Smart Charging: Optimized battery lifecycle management.

Technical Specs

Rated Power	5000VA / 5000W
Surge Power	10000VA
Battery Voltage	48 VDC
AC Input Voltage	230 VAC
Max PV Input	500 VDC
MPPT Charge Current	80 A
MPPT Voltage Range	120 ~ 450 VDC
Peak Efficiency	93%

System Type	Compatibility	Notes
Solar Systems	Off-Grid PV Arrays	Max 5000W PV Power
Battery Banks	48V Lithium / Lead-Acid	Configurable charge profiles
Backup Power	UPS / Emergency Backup	<20ms transfer time

Installation should be performed by a qualified electrician or solar technician. Ensure correct cable sizing for the 48V battery connection and adhere to local electrical standards for PV array grounding. Refer to the included manual for LCD configuration of battery types (AGM, Flood, User-defined/Lithium).

Is this a genuine original part?

This is a premium quality aftermarket replacement part, manufactured to meet or exceed original equipment (OE) standards for off-grid power performance.

How do I know if it is compatible?

We recommend checking your current system's battery voltage (must be 48V) and ensuring your total load does not exceed 5000W continuous. This SKU matches the Axpert VM II series architecture.

Can this inverter run without a battery connected?

Yes, the VMPLUS-II-48-5000 features a battery-independent design, meaning it can provide power to connected AC loads directly from the solar panels if sufficient sunlight is available.
