Victron BlueSolar MPPT 150/60 Solar Charge Controller
60A | 150V PV Input | 12V, 24V, 36V, 48V Battery Systems
The Victron BlueSolar MPPT 150/60 60A Solar Charge Controller is engineered for efficient and intelligent solar energy harvesting and battery management. This advanced MPPT (Maximum Power Point Tracking) controller optimises power extraction from your solar panels, ensuring maximum energy yield even under challenging conditions like partial shading or fluctuating light intensity.
Designed for a wide range of off-grid and grid-tied solar applications, the BlueSolar 150/60 supports 12V, 24V, 36V, and 48V battery systems, with a maximum PV open circuit voltage of 150V. Its robust design and comprehensive protection features make it a reliable choice for maintaining optimal battery health and extending battery lifespan.
KEY TECHNOLOGY: Utilises ultra-fast MPPT to boost energy harvest by up to 30% compared to PWM controllers and 10% over slower MPPT models.
Key Features
| ▶ Ultrafast MPPT Technology — Maximises energy harvest from your solar array, even in dynamic weather conditions. |
| ▶ Advanced MPP Detection — Optimises performance during partial shading, ensuring consistent power output. |
| ▶ Intelligent BatteryLife Algorithm — Extends battery lifespan by preventing over-discharge and ensuring regular full charges. |
| ▶ VE.Direct Communication Port — Enables connection to Victron accessories for monitoring and advanced programming. |
| ▶ High Conversion Efficiency — Achieves over 98% peak efficiency without the need for a cooling fan. |
| ▶ Wide Battery Compatibility — Supports AGM, Gel, Tubular plate, and Lithium battery types with flexible charge algorithms. |
| ▶ Robust Environmental Rating — IP43 for electronic components and PD3 pollution degree for durability. |
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Victron Energy |
| Model | BlueSolar MPPT 150/60 |
| Part Number (MPN) | SCC010060200 (Tr model) |
| Battery Voltage | 12V / 24V / 36V / 48V Auto Select |
| Rated Charge Current | 60A |
| Max. PV Open Circuit Voltage | 150V |
| Max. PV Power (12V System) | 860W |
| Max. PV Power (24V System) | 1720W |
| Max. PV Power (36V System) | 2580W |
| Max. PV Power (48V System) | 3440W |
| Peak Efficiency | > 98% |
| Self-Consumption | <35mA (12V) / <20mA (48V) |
| Operating Temperature | -30°C to +60°C |
| Protection Rating | IP43 (electronics) / IP22 (connection area) |
| Pollution Degree | PD3 |
| Dimensions (H x W x D) | 250 x 185 x 95 mm |
| Weight | 3 kg |
Charging & Battery Modes
The Victron BlueSolar MPPT 150/60 offers flexible charging capabilities to suit various battery technologies and system requirements. Its adaptive 3-stage charging algorithm (Bulk, Absorption, Float) ensures efficient and safe charging, prolonging battery life.
| Feature | Description |
|---|---|
| Adaptive 3-Stage Charging | Ensures optimal charging with Bulk, Absorption, and Float stages, adapting to battery condition. |
| Programmable Charge Algorithm | Offers eight pre-programmed algorithms or allows user-defined settings via VictronConnect for specific battery types. |
| Temperature Compensation | Internal temperature sensor adjusts charge voltages to prevent over or under-charging in varying temperatures. |
| 36V System Support | Manual selection for 36V battery systems is available through the MPPT Control panel or VictronConnect App. |
Typical Applications
| Application | Description |
|---|---|
| Off-Grid Solar Systems | Ideal for cabins, remote homes, and standalone power systems where grid connection is unavailable. |
| RV, Caravan & Marine | Provides reliable battery charging for leisure vehicles and boats, maximising solar yield on the move. |
| Small Business & Backup Power | Suitable for small commercial installations or as part of a backup power solution to keep essential systems running. |
| Industrial & Telecommunications | Robust design and wide operating temperature range make it suitable for demanding industrial and telecom sites. |
Built-In Protection Functions
The Victron BlueSolar MPPT 150/60 is equipped with extensive electronic protection features to ensure safe and reliable operation. These include protection against PV short circuit • PV reverse polarity • PV reverse current • Battery reverse polarity • Battery overheating (via internal sensor) • Over-temperature protection with power derating. The unit also features self-diagnostic capabilities with LED indicators for system errors.
Common Questions
What is the maximum solar panel voltage this controller can handle?
The Victron BlueSolar MPPT 150/60 can handle a maximum PV open circuit voltage of 150V. It is crucial to ensure your solar array's open circuit voltage (Voc) does not exceed this limit, especially in cold conditions where voltage can be higher.
Can I monitor and configure this controller remotely?
Yes, the controller features a VE.Direct communication port. By connecting an optional VE.Direct Bluetooth Smart dongle or VE.Direct USB cable (both sold separately), you can monitor and configure the unit using the VictronConnect App on your smartphone, tablet, or computer. An optional MPPT Control panel is also available.
Is this controller suitable for lithium batteries?
Yes, the Victron BlueSolar MPPT 150/60 is compatible with a wide range of battery types, including Lithium batteries. Its flexible and programmable charge algorithm allows you to set specific charging parameters suitable for lithium chemistry via the VictronConnect App.
What is the "BatteryLife" feature?
BatteryLife is an intelligent battery management feature that gradually increases the load disconnect voltage if the controller fails to achieve a full charge daily. This adaptive mechanism helps prevent repeated partial discharge cycles, which can significantly extend the overall lifespan of your battery bank.
Installation Notes
- Ensure installation is carried out by a qualified professional in accordance with local electrical regulations.
- Mount the controller in a dry, well-ventilated area, close to the batteries but not directly above them.
- Allow at least 10 cm of clearance around the unit for proper cooling and airflow.
- Use appropriate cable gauges for PV and battery connections to minimise voltage drop and ensure safety.
- Always connect the battery first, then the solar panels. Disconnect in reverse order.
Before You Buy
- Verify your total solar panel array voltage (Voc) does not exceed 150V under any conditions.
- Confirm your battery bank voltage (12V, 24V, 36V, or 48V) matches the controller's capabilities.
- Consider optional accessories like the VE.Direct Bluetooth Smart dongle or MPPT Control panel for enhanced monitoring and control.
- Review the detailed user manual for comprehensive wiring diagrams and operational guidelines.
- Ensure the chosen installation location meets the environmental requirements (IP rating, temperature).
Always verify product specifications and compatibility with your specific solar system components before purchase and installation. This product is covered by a 5-year warranty.
