RELIABILITY: Built to withstand the rigours of mobile and marine environments, featuring an IP65 rating and a wide operating temperature range to ensure consistent performance in all conditions.

Key Features

• ✔ 5-Level Detection: Monitors at 0%, 25%, 50%, 75%, and 100%.
• ✔ Top Installation: Simplified mounting for various tank types.
• ✔ Communication Cable: Includes a 5m cable for flexible setup.
• ✔ Conductive Design: No moving parts for maximum longevity.

Technical Specs

Length:	400mm
IP Rating:	IP65
Operating Temp:	0°C to +85°C
Detection Points:	5 Levels
Cable Length:	5 Metres

System/Make	Application	Notes
TBB Power Mezzo III	RV / Motorhome	Direct digital integration
TBB Power Amoy	Marine / Specialist Vehicle	Standard for Amoy-KIT systems
Water Tanks	Freshwater / Wastewater	Conductive sensing required

Designed for top-down installation into the water tank. Drill the appropriate sized hole in the top of the tank, insert the 400mm probe, and secure the mounting flange. Connect the 5m communication cable directly to the TBB Power master module (Mezzo or Amoy) and configure via the system monitor or mobile app. Professional installation is recommended for optimal sealing and data accuracy.

Is this a genuine original part?

This is a genuine TBB Power accessory supplied by Solarika, specifically designed to meet original equipment standards for their power management ecosystems.

How do I know if it is compatible?

If you are using a TBB Power Mezzo or Amoy system, this is the correct sensor. Please ensure your tank depth is at least 400mm to accommodate the full probe length.

Can it be used with analogue water level gauges?

No, this is a digital conductive sensor designed to communicate specifically with TBB Power control modules. It will not work with standard resistance-based analogue gauges.
