Iconica Max 8000W 48V hybrid pure sine wave inverter with combined 8000W dual-input solar MPPT controller, 120A solar charging current, 120A mains battery charger, parallel capability and inbuilt Wi-Fi mobile monitoring (No battery required)
Iconica Max 8000W 48V hybrid pure sine wave inverter with combined 8000W dual-input solar MPPT controller, 120A solar charging current, 120A mains battery charger, parallel capability and inbuilt Wi-Fi mobile monitoring (No battery required)
SKU:IC-MX8000-48
Our stock levels are dynamic and can change frequently. If a product appears to be in stock, it may have already sold out. Please contact us if you have any questions about availability. Thank you for your understanding.
Couldn't load pickup availability
IC-MX8000-48 Hybrid Inverter
8000W 48V Pure Sine Wave Inverter & Dual MPPT Controller
The Iconica IC-MX8000-48 is a high-performance hybrid inverter charger designed for sophisticated off-grid and backup power applications. Combining an 8000W pure sine wave inverter, a dual-input MPPT solar charge controller, and a high-speed mains battery charger, this unit provides a comprehensive energy management solution for 48V battery systems.
Key Features
- ✔ Dual MPPT Inputs: Accepts up to 8000W of PV (4000W per input).
- ✔ Battery Independence: Powers loads from PV without a battery bank.
- ✔ Parallel Ready: Connect up to 6 units for large-scale power needs.
- ✔ Smart Monitoring: Built-in Wi-Fi for mobile app tracking.
- ✔ Removable LCD: Detachable display for remote mounting.
Technical Specs
| Continuous Power | 8000W / 8000VA |
| Surge Power | 16000VA |
| Battery Voltage | 48V DC |
| Max Solar Input | 8000W (2x 4000W) |
| Max PV Voc | 500V DC |
| MPPT Range | 90V – 450V DC |
| Max Charging Current | 120A (Solar/Mains) |
| Net Weight | 18.4 kg |
Compatibility / Fitment Guide
| System Type | Battery Application | Notes |
|---|---|---|
| 48V Off-Grid | LiFePO4 / Lithium | BMS communication port included. |
| 48V Off-Grid | AGM / GEL / Flooded | Customizable charging profiles. |
| Home Backup | UPS Mode | Transfer time: 10ms (PC) / 20ms (Appliance). |
OEM Cross Reference
| Manufacturer | Part Number / Series |
| Iconica | IC-MX8000-48 |
| Voltronic Power | Axpert MAX II 8000-48 (Equivalent Base) |
| EAN | 5060297347191 |
Installation Guide
Installation should be performed by a qualified electrician or solar professional. Key steps include:
- Securely mount vertically on a non-flammable surface.
- Ensure adequate ventilation clearance around the unit's cooling fans.
- Connect 48V battery bank using recommended cable gauges (refer to manual for AWG).
- Connect PV arrays to the dual MPPT inputs (ensure Voc does not exceed 500V).
Questions & Answers
Is this a genuine original part?
This is a premium Iconica brand hybrid inverter, manufactured to the highest standards for the UK and European off-grid market.
How do I know if it is compatible?
We recommend checking the IC-MX8000-48 SKU. If your system requires a 48V input and up to 8kW of continuous output, this unit is compatible. It supports Lithium, AGM, and GEL batteries.
Can this inverter run without a battery connected?
Yes, the IC-MX8000-48 features a battery-independent mode, allowing it to power your household loads directly from solar panels during daylight hours without a battery bank.
Note: Please verify your system voltage (48V) and power requirements before purchasing. Technical support is available via Solarika.co.uk.
