Iconica 5000W 48V pure sine wave inverter with zero transfer, 4000W solar input, 80A MPPT solar controller
Iconica 5000W 48V pure sine wave inverter with zero transfer, 4000W solar input, 80A MPPT solar controller
SKU:IC-ZT5000-48
Our stock levels are dynamic and can change frequently. If a product appears to be in stock, it may have already sold out. Please contact us if you have any questions about availability. Thank you for your understanding.
Couldn't load pickup availability
Iconica 5000W 48V Hybrid Pure Sine Wave Inverter
Zero Transfer UPS | 4000W MPPT Solar | Parallel Ready
The Iconica 5000W 48V Hybrid Pure Sine Wave Inverter, SKU IC-ZT5000-48, is a versatile all-in-one power management system designed for off-grid, hybrid, and backup energy applications. Manufactured by Photonic Universe, this robust unit seamlessly integrates a powerful 5000W pure sine wave inverter, an 80A MPPT solar charge controller, and a 60A smart mains battery charger. It can draw power from solar panels, mains electricity, a generator, or batteries, individually or in combination, to ensure a reliable and uninterrupted power supply.
Ideal for remote properties, holiday homes, workshops, and critical IT setups, this inverter provides clean, stable 230V AC power for a wide range of appliances. Its advanced features, including zero transfer time UPS functionality and Bluetooth connectivity, offer enhanced control and peace of mind for energy independence.
KEY CAPABILITY: This Iconica inverter supports battery-free operation, allowing it to power AC loads directly from solar input.
Key Features
| ▶ Pure Sine Wave Output — Ensures safe and efficient operation for sensitive electronics. |
| ▶ Zero Transfer Time UPS — Provides instant 0ms switchover for critical loads during power outages. |
| ▶ Integrated MPPT Controller — High-efficiency 80A MPPT solar charge controller with up to 4000W solar input. |
| ▶ Smart Mains Charger — Built-in 60A smart battery charger for fast and safe charging from grid or generator. |
| ▶ Parallel & 3-Phase Capability — Expandable up to 9 units (45kW total) with optional kits for larger systems. |
| ▶ Bluetooth Connectivity — Monitor system performance wirelessly via the Watchpower mobile app. |
| ▶ Battery-Free Operation — Can power AC loads directly from solar panels without a connected battery. |
| ▶ Customisable Settings — Advanced menu for tailoring charging, load priorities, and operational preferences. |
Technical Specifications
| Parameter | Value |
|---|---|
| Model | IC-ZT5000-48 |
| Continuous Power | 5000W / 5000VA |
| Surge Power | 10,000VA |
| Battery Voltage | 48V DC |
| Output Waveform | Pure Sine Wave |
| Max Solar Input Power | 4000W |
| Max Solar Open Circuit Voltage | 145V DC |
| MPPT Operating Voltage Range | 60 - 115V DC |
| Max Solar Charging Current | 80A |
| Max Mains AC Charging Current | 60A |
| Max Combined Charging Current | 140A |
| Peak Efficiency | 93% |
| Operating Temperature | 0°C to 55°C |
| Dimensions (L x W x H) | 52.5 x 30.3 x 14 cm |
| Weight | 13.5 kg |
Operating & Power Guidance
| Function | Description |
|---|---|
| Power Sources | Accepts input from solar panels, mains electricity, a generator, or a battery bank, allowing flexible energy management. |
| Output Source Priority | User-configurable settings to prioritise solar, battery, or mains/generator input for AC load output. |
| Battery Charging Priority | Multiple options to set charging preferences from solar or AC sources. |
| Monitoring & Control | Inbuilt Bluetooth for mobile app monitoring (Watchpower) and PC software for detailed data logging and customisation. |
Typical Applications
| Application | Description |
|---|---|
| Off-Grid Homes & Cabins | Provides reliable 230V AC power for domestic appliances in remote locations without mains grid access. |
| Backup Power Systems | Acts as an Uninterruptible Power Supply (UPS) for homes or businesses in areas with frequent power cuts, protecting critical loads. |
| Mobile Installations | Suitable for narrowboats, yachts, and motorhomes, offering stable power on the move. |
| Workshops & Garages | Capable of running power tools and other demanding equipment with its 10,000VA surge capacity. |
Built-In Protection Functions
The Iconica 5000W 48V Hybrid Inverter incorporates multiple safety features to ensure reliable and protected operation. These include comprehensive protection against overcharge, overheating, and reverse current for the solar charge controller. The smart battery charger also features full overcharge protection and multi-stage charging profiles. Its robust design contributes to long-term system safety and stability.
Common Questions
What does "zero transfer time" mean?
Zero transfer time (0ms) means the inverter switches instantly from mains power to battery power in the event of an outage. This is crucial for sensitive electronics like computers and servers, ensuring uninterrupted operation.
Can this inverter operate without batteries?
Yes, a key feature of this Iconica hybrid inverter is its ability to power AC loads directly from the solar panel input, even without a battery bank connected.
What type of batteries are compatible?
This hybrid inverter is suitable for 48V flooded and sealed GEL/AGM lead-acid batteries with pre-defined charging programs. A user-defined battery type with customisable settings is also available for other lead-acid battery types.
Can I expand my system with more inverters?
Yes, this inverter supports parallel operation with up to 8 additional identical units, allowing for large-scale system expansion up to 45kW total capacity. It also supports three-phase configuration with parallel connection kits (sold separately).
Installation Notes
- Installation should be performed by a qualified professional to ensure safety and compliance with local regulations.
- Ensure adequate ventilation around the inverter to prevent overheating.
- The solar array must meet the minimum MPPT input voltage of 60V DC (achieved by connecting multiple panels in series) to enable solar charging or direct load operation.
- Refer to the detailed user manual for comprehensive wiring diagrams and operational instructions.
Before You Buy
- Verify your total power requirements (continuous and surge) to ensure this 5000W inverter meets your needs.
- Confirm your battery bank voltage is 48V for compatibility.
- Consider future expansion needs; parallel connection kits are sold separately if you plan to link multiple units.
- Review the MPPT operating voltage range (60-115V DC) to match your solar panel configuration.
Always verify product specifications and compatibility with your specific system components before purchase. Consult a qualified installer for system design and installation advice.
