EPEVER 40A MPPT Controller XTR4415N

Premium 150V DC Solar Power Management

The Solarika XTR4415N (XTRA Series) is a professional-grade MPPT solar charge controller engineered for high-efficiency energy harvesting. Utilizing advanced Maximum Power Point Tracking technology, this unit ensures your solar panels operate at their peak performance regardless of weather conditions, delivering up to 30% more power than standard PWM controllers.

RELIABILITY: Features a robust die-cast aluminum heat sink and comprehensive electronic protections to ensure stable operation in demanding environments.

Key Features

  • ✔ Advanced MPPT: Tracking efficiency ≥ 99.5%.
  • ✔ Multi-Voltage: Auto-detects 12V/24V/36V/48V DC.
  • ✔ Common Negative: Ideal for RV and Marine grounding.
  • ✔ LCD Display: Real-time monitoring and parameter setup.
  • ✔ Lithium Ready: Dedicated charging profiles for LiFePO4.

Technical Specs

Rated Charge Current: 40A
Max PV Input Voltage: 150V (138V at 25°C)
Max PV Power (12V): 520W
Max PV Power (24V): 1040W
Max PV Power (48V): 2080W
Terminals: 16mm² / 6AWG
Enclosure: IP33

Battery Compatibility Guide

Battery Type Compatibility Notes
Lead-Acid Sealed (AGM), Gel, Flooded Standard profiles included.
Lithium LiFePO4, Li(NiCoMn)O2 Supports manual voltage setting.
User Defined Custom Voltage Ranges Requires MT50 or USB cable for setup.

OEM Cross Reference

EPEVER XTRA4415N, XTRA4415N-XDS2
Photonic Universe XTRA4415N (40A MPPT)
Other References N-Series 40A 150V MPPT

Installation Guide

Sequence: Always connect the Battery first, then the Solar Panels. For disconnection, remove the Solar Panels first, then the Battery.

Mounting: Install vertically in a well-ventilated area. Ensure a minimum of 150mm clearance around the heat sink for optimal cooling.

Questions & Answers

Is this a genuine original part?

Yes, this is an authentic EPEVER XTRA series controller, supplied by Solarika. It is a premium-tier MPPT unit manufactured to industrial standards.

How do I know if it is compatible with my panels?

Ensure the total Open Circuit Voltage (Voc) of your solar array does not exceed 150V and that the wattage aligns with your battery system voltage (e.g., max 1040W for a 24V battery).

Can I use this with a 48V battery system?

Absolutely. The XTR4415N features automatic system voltage recognition for 12V, 24V, 36V, and 48V battery banks.

Note: Please verify your battery voltage and PV array specs against the references above before purchasing. Domain: Solarika.co.uk
