EBOX-BT Bluetooth Module for Solar Charge Controllers
Wireless Monitoring & Programming | RJ45 Connection | 1.9m Cable
The Photonic Universe EBOX-BT Bluetooth Module is designed to enhance your solar power system by enabling wireless communication with compatible solar charge controllers. This essential accessory allows you to monitor and program your solar charge controller directly from your mobile device using a dedicated app, providing convenience and greater control over your energy setup.
Ideal for UK homeowners, off-grid users, and small businesses, the EBOX-BT module unlocks a range of exclusive settings within the mobile application. You can view real-time charging parameters, store historical data, and adjust critical settings such as battery type, charging stages, and load configurations, all from up to 10 metres away.
COMPATIBILITY NOTE: This module is specifically designed for single-battery solar charge controllers and is not suitable for dual battery systems.
Key Features
| ▶ Wireless Monitoring — Connects your solar charge controller to a mobile app for remote access. |
| ▶ Comprehensive Control — Adjust battery type, capacity, charging stages, and load settings via the app. |
| ▶ Real-time Data Display — View voltage, current (solar/load), and battery state of charge (SoC). |
| ▶ Historical Data Storage — Records accumulated charge/discharge energy and min/max voltage readings. |
| ▶ Extended Communication Range — Offers a wireless radius of up to 10 metres. |
| ▶ Easy Installation — Supplied with a 1.9m RJ45 cable for direct plug-and-play setup. |
| ▶ Low Power Consumption — Operates efficiently at 5V @ 30mA, minimising system drain. |
| ▶ Status Indicators — Built-in LEDs show power and network connection status. |
Technical Specifications
| Parameter | Value |
|---|---|
| Model | EBOX-BT |
| Manufacturer | Photonic Universe |
| Product Type | Bluetooth Module |
| Communication Radius | Up to 10m |
| Cable Length | 1.9m |
| Connection Type | RJ45 |
| Power Consumption | 5V @ 30mA |
| Port Baud Rate | 2400bps-115200bps (Default 115200bps) |
| Enclosure Rating | IP30 |
| Dimensions (L x W x H) | 51 x 67 x 24.5mm |
| Weight | 37.9g |
Enhanced System Management
The EBOX-BT module, when paired with its mobile app, transforms how you interact with your solar charge controller. It provides a user-friendly interface to access and modify crucial system parameters, ensuring your solar setup operates optimally for your specific needs.
| Functionality | Description |
|---|---|
| Parameter Adjustment | Easily amend battery type, capacity, and select charging voltages for different stages. |
| Load Control | Personalise load settings, including setting timers for connected devices like lighting, fans, or pumps. |
| Monitoring Data | Access real-time data on solar panel voltage, current (solar/load), and battery state of charge (SoC). |
| Custom Profiles | Create user-defined battery types with specific charging parameters to match unique battery requirements. |
Typical Applications
| Application | Description |
|---|---|
| Off-Grid Solar Systems | Enables remote monitoring and adjustment of charge controller settings in cabins, sheds, or remote installations. |
| Home Solar Installations | Conveniently manage and optimise battery charging and load usage from a mobile device within your home. |
| RV & Marine Setups | Monitor solar performance and adjust parameters in caravans, motorhomes, or boats without needing direct access to the controller. |
| Small Business Solar | Provides a simple way to oversee and manage solar charge controllers in small commercial applications. |
Design & Connectivity Features
The EBOX-BT module is engineered for reliable performance with minimal impact on your solar system. Its low power consumption of 5V @ 30mA ensures efficient operation. • The IP30 enclosure rating provides basic protection against solid objects larger than 2.5mm. • It features a standard RJ45 connection, making it compatible with a wide range of solar charge controllers.
Common Questions
What solar charge controllers is the EBOX-BT compatible with?
The EBOX-BT is compatible with specific Photonic Universe and similar series controllers, including Tracer TR/PTR, VS****BN, DM, MSC, LS**24B, and PU series. Always verify your controller's model number against the compatibility list.
Can I use this module with a dual battery solar charge controller?
No, this Bluetooth module is specifically designed for single-battery solar charge controllers and is not suitable for dual battery systems.
What is the communication range of the EBOX-BT module?
The module offers a wireless communication radius of up to 10 metres, allowing you to monitor and program your controller from a convenient distance.
What kind of cable does it use and can I replace it?
It comes with a 1.9m RJ45 cable. You can replace this cable with a shorter or longer standard RJ45 cable if needed. For controllers with an RS485 port, an additional RS485 to RJ45 adapter cable will be required for connection.
Installation Notes
- Connect the EBOX-BT module to the designated RJ45 port on your compatible solar charge controller.
- Ensure the 1.9m cable is securely connected at both ends.
- For controllers with an RS485 port, an additional RS485 to RJ45 cable (not included) will be necessary.
- Mount the module in a location within 10 metres of your mobile device for optimal Bluetooth communication.
- Refer to your solar charge controller's user manual for specific port locations and connection instructions.
Before You Buy
- Verify your solar charge controller's model number against the compatible series (Tracer TR/PTR, VS****BN, DM, MSC, LS**24B, PU).
- Confirm your controller is for a single battery system; this module is not for dual battery controllers.
- Check if your controller has an RJ45 port or requires an RS485 to RJ45 adapter cable.
- Ensure you have a compatible iOS or Android mobile device to download and use the free pairing app.
Please verify compatibility with your specific solar charge controller model before purchase. Specifications are subject to change by the manufacturer.
