60A 12V DC to 12V DC Advanced Automatic Multi-Stage Triple Battery Charger with 30A MPPT solar input and 40A mains input for Lead Acid and Lithium Batteries
60A 12V DC to 12V DC Advanced Automatic Multi-Stage Triple Battery Charger with 30A MPPT solar input and 40A mains input for Lead Acid and Lithium Batteries
SKU:DCTRIPLE-60
Our stock levels are dynamic and can change frequently. If a product appears to be in stock, it may have already sold out. Please contact us if you have any questions about availability. Thank you for your understanding.
Couldn't load pickup availability
60A 12V TRIPLE BATTERY CHARGER [DCTRIPLE-60]
The Ultimate 3-in-1 Charging Solution for 12V Systems
The DCTRIPLE-60 is a sophisticated, all-in-one power management system designed for leisure vehicles, marine vessels, and high-demand off-grid applications. This advanced unit combines three essential charging sources into a single compact device: a high-powered 60A DC-to-DC (battery-to-battery) charger, a 30A MPPT solar charge controller, and a 40A mains AC-to-DC charger.
Key Features
- ✔ 60A DC-DC: Fast charging from alternator
- ✔ 30A MPPT: Built-in solar efficiency
- ✔ 40A Mains: Seamless grid/hookup charging
- ✔ AES Control: Automatic fridge energy selection
- ✔ Lithium Ready: Specific LiFePO4 & NCM profiles
Technical Specs
| Output Voltage: | 12V DC |
| Max DC-DC Current: | 60A |
| Max AC Current: | 40A |
| Max Solar Current: | 30A |
| Max Solar Input: | 430W / 50V VOC |
| Dimensions: | 285 x 234 x 74 mm |
| Weight: | 2.3 kg |
Compatibility / Fitment Guide
| Application | Battery Chemistry | Capacity Range |
|---|---|---|
| Motorhomes & Vans | Lead Acid, AGM, Gel, LiFePO4 | 90Ah - 560Ah |
| Marine Vessels | GEL, AGM, Deep Cycle | 90Ah - 560Ah |
| Commercial Vehicles | Standard Flooded, EFB | 90Ah+ Recommended |
OEM Cross Reference
| Part Number / SKU | DCTRIPLE-60 |
| EAN | 5060297348914 |
| Brand Reference | Photonic Universe Advanced Triple Charger |
Installation Notes
- Designed for 12V systems only. Do not use with 24V batteries.
- Features a D+ terminal for alternator synchronization (Euro 6 compliant).
- Includes pluggable terminal blocks for easier wiring in tight spaces.
- Ventilated installation is recommended to ensure optimal high-current performance.
Questions & Answers
Is this a genuine original part?
This is a premium Solarika equipment part manufactured to the exact DCTRIPLE-60 specifications, offering industrial-grade performance for off-grid power systems.
How do I know if it is compatible?
This unit is compatible with almost all 12V Lead Acid and Lithium battery types. Check your battery bank capacity—it is optimized for banks between 90Ah and 560Ah.
Does it charge the starter battery from solar?
Yes, the DCTRIPLE-60 features a trickle charge function (0A-5A) that can maintain the source/starter battery using solar energy once the target leisure battery is fully charged.
Note: Professional installation by a qualified electrician is recommended for high-current DC systems. Distributed by Solarika.co.uk.
