RELIABILITY: Engineered with a high-speed MPPT controller and pure sine wave output to provide clean, stable power equivalent to the grid.

Key Features

• ✔ Zero Transfer Time: Instant 0ms switching
• ✔ Built-in MPPT: 80A solar charge controller
• ✔ High Surge Capacity: 10,000VA peak power
• ✔ Parallel Ready: Can be expanded for more power
• ✔ Pure Sine Wave: Safe for all sensitive loads

Technical Specs

Rated Power	5000W / 5000VA
Battery Voltage	48V DC
Output Voltage	230V AC ±5%
Transfer Time	0 ms (Zero Transfer)
Max PV Power	4000W
Max PV Voltage	145V DC (Voc)
Charge Current	80A Solar / 60A AC

System Component	Compatibility Requirements	Notes
Battery Banks	48V (Lead Acid, AGM, Gel, Lithium)	User-defined charging profiles
Solar Panels	60V - 115V MPPT Operating Range	Max 4000W PV Input
IT Systems	Servers, Data Centers, PCs	Zero transfer prevents downtime

This unit is designed for wall-mount installation. Professional installation by a certified electrician is required. Ensure the battery bank is correctly configured to 48V before connection. For PV wiring, ensure the Open Circuit Voltage (Voc) of the solar array does not exceed 145Vdc under cold weather conditions.

Is this a genuine original part?

This is a premium quality professional solar inverter from the Solarika range, manufactured to exceed OEM standards for high-availability power applications.

How do I know if it is compatible?

If you are replacing a 48V hybrid inverter or building a new 5kW system, this unit is compatible as long as your battery voltage is 48V. Please check the cross-reference list if replacing a Photonic Universe or Axpert unit.

Why do I need Zero Transfer (0ms)?

Most standard inverters have a 10-20ms "gap" when the grid fails. This gap is long enough to cause computers, game consoles, and servers to reboot. The UPS-ZT5K-48 eliminates this gap completely, keeping your digital life online.
