RELIABILITY: Features an intelligent Battery Management System (BMS) and high-grade LiFePO4 cells offering over 6,000 cycles at 90% Depth of Discharge.

Key Features

• ✔ Scalable Design: Parallel up to 32 modules
• ✔ Advanced Comms: CAN and RS485 support
• ✔ Fast Charging: Supports up to 105A current
• ✔ Auto-Address: Easy setup for parallel units
• ✔ Smart Safety: Full OVP, UVP, and OTP protection

Technical Specs

Nominal Voltage	48V DC
Working Voltage	42V – 54.75V
Nominal Capacity	105Ah
Energy Capacity	5.04kWh
Standard Charge/Discharge	52.5A
Max Charge/Discharge	105A
Cycle Life	6000+ (@90% DoD)
Weight	40 kg
Dimensions	482.6 x 133.4 x 450 mm

System Type	Compatible Brands	Notes
Solar Inverters	Victron Energy, TBB Power, Studer	Compatible via CAN/RS485 communication protocols.
Hybrid Systems	TBB RIIOSUN-II Series, Matrix II	Plug-and-play integration with TBB ecosystems.
Off-Grid Kits	Standard 48V DC Systems	Requires compatible battery cabinet or rack.

This module is designed for 19-inch rack installation. Always ensure the system is powered down before making connections. Use appropriate DC cabling (recommended 25-35mm²) and ensure the communication cables (RJ45) are correctly seated for parallel operation. For multi-battery banks, the ES100 II automatically assigns slave addresses, simplifying configuration.

Is this a genuine Solarika supplied part?

Yes, this is a premium TBB Power ES100 II module supplied by Solarika. It is manufactured to industrial standards for high-reliability energy storage.

How do I know if it is compatible with my inverter?

The ES100 II supports CAN and RS485 communication. It is natively compatible with Victron, Pylontech-compatible protocols, and the full range of TBB RIIOSUN/Matrix inverters.

What is the maximum number of batteries I can connect?

Standard configuration allows for up to 32 modules in parallel. For larger industrial applications, up to 160 modules can be connected using an external communication hub.
