3600W 48V hybrid grid tie / off-grid inverter with 5400W 500V solar input, dual MPPT and 75A mains charger
3600W 48V hybrid grid tie / off-grid inverter with 5400W 500V solar input, dual MPPT and 75A mains charger
SKU:STG-PH3600-48
Our stock levels are dynamic and can change frequently. If a product appears to be in stock, it may have already sold out. Please contact us if you have any questions about availability. Thank you for your understanding.
Couldn't load pickup availability
Solarika 3.6kW 48V Hybrid Inverter
SKU: STG-PH3600-48 | Dual MPPT | IP65 Rated
The Solarika STG-PH3600-48 is a premium 3.6kW hybrid bidirectional inverter designed to maximize energy independence for residential and commercial solar systems. This intelligent unit seamlessly manages energy flow between your solar panels, 48V battery storage, and the utility grid, ensuring you prioritize self-consumption and maintain power during outages.
Key Features
- ✔ Dual MPPT Trackers: Optimized for two independent solar arrays.
- ✔ IP65 Weatherproof: Suitable for outdoor installation.
- ✔ Multi-Mode Operation: Grid-tie, Off-grid, and Battery Backup.
- ✔ Smart Monitoring: Integrated Wi-Fi for remote app management.
- ✔ Quiet Operation: Fanless cooling system reduces maintenance.
Technical Specs
| Rated Power: | 3600W (3.6kW) |
| Nominal Battery Voltage: | 48V DC |
| Max PV Input Power: | 5400W |
| MPPT Voltage Range: | 120V - 500V DC |
| Max Charge Current: | 75A |
| Peak Power (10s): | 6000VA |
| Dimensions: | 480 x 420 x 199 mm |
Battery Compatibility Guide
| Battery Type | Voltage | Notes |
|---|---|---|
| Lithium (LiFePO4) | 48V | Recommended for high efficiency and longevity. |
| AGM / Gel / Sealed | 48V | Fully compatible with built-in charging profiles. |
| Flooded Lead Acid | 48V | Supported with adjustable voltage settings. |
OEM & Cross Reference
| Part Number: | STG-PH3600-48 |
| Series Reference: | Stellar 3.6kW 48V Hybrid / STG-PH Series |
| Enclosure Rating: | IP65 (NEMA 4X equivalent) |
Installation & Safety
This inverter must be installed by a qualified electrical professional in accordance with local regulations. It features a fanless design for quiet operation and is IP65 rated, allowing for flexible mounting options both indoors and outdoors. Ensure all DC and AC wiring is correctly sized for a 3600W load to prevent voltage drop.
Questions & Answers
Is this a genuine Solarika product?
Yes, this is a premium Solarika STG series hybrid inverter, manufactured to the highest standards for performance and reliability in UK and EU power systems.
Does it work during a power cut?
Yes, when configured with a 48V battery system, the STG-PH3600-48 provides an "Off-Grid" mode that can supply power to your critical loads during a grid failure.
Can I monitor this from my phone?
Yes, the inverter includes integrated Wi-Fi connectivity and is compatible with the SmartValue mobile app for real-time performance tracking and settings management.
Note: Please verify your system voltage (48V) and solar array parameters before purchasing. This is a technical solar component for photovoltaic systems.
