SMART TECHNOLOGY: Fully compatible with modern Smart Alternators (Euro 5/6) and features an integrated MPPT Solar Controller for seamless charging from solar panels when the engine is off.

Key Features

• ✔ Dual Input: Charge via alternator or solar
• ✔ MPPT Integrated: Maximises solar harvest efficiency
• ✔ 3-Stage Charging: Bulk, Absorption, and Float
• ✔ Smart Alternator Ready: Works with Euro 5/6 engines
• ✔ Battery Protection: Low battery shut-off and sleep mode

Technical Specs

Output Current	30 Amps
System Voltage	12V DC
Solar Controller	Built-in MPPT
Solar Max Voltage	30V DC
Compatible Chemistries	Lead Acid, AGM, Gel, Calcium
Operating Temp	-10°C to +45°C

Application	System Compatibility	Notes
Campervans / Motorhomes	All 12V Leisure Systems	Ideal for Euro 6 transit/VW/Merc vans
Marine / Boats	House Battery Banks	Supports multi-chemistry banks
Commercial Vehicles	Auxiliary Power Systems	Provides stable charging for tail lifts/tools

The unit should be installed as close to the auxiliary battery as possible. Ensure correct cable sizing for 30A continuous load to prevent voltage drop. Connection requires an ignition feed (D+) for vehicles with smart alternators to trigger the charging cycle. Professional installation is heavily recommended if you are unsure of automotive electrical systems.

Is this a genuine original part?

This is a premium quality unit from Ring Automotive, a leader in vehicle lighting and power electronics, supplied by Solarika.

How do I know if it is compatible?

If you have a 12V vehicle and wish to charge a leisure battery while driving, this is the correct solution. It is specifically designed to work with "Smart Alternators" found in Euro 5 and Euro 6 vehicles.

Can I use solar panels and the alternator at the same time?

Yes, the DCTRIPLE30 is designed to manage dual inputs. It features an integrated MPPT controller that prioritises the best available power source to charge your battery.
