RELIABILITY: Features an advanced tail furling mechanism that automatically pivots the turbine away from abnormally high winds to protect the generator and blades from damage.

Key Features

• ✔ 3-Blade Design: Optimized for medium and high wind speeds.
• ✔ Tail Furling Safety: Mechanical overspeed protection.
• ✔ Die-Cast Aluminum: Corrosion-resistant housing.
• ✔ 3-Phase AC Output: High-efficiency permanent magnet generator.
• ✔ Low Start-up: Begins generation at just 2.5 m/s.

Technical Specs

Rated Power	3000W
Rated Voltage	120V AC (3-Phase)
Start-up Wind Speed	2.5 m/s
Rated Wind Speed	12 m/s
Rotor Diameter	3.8 Meters
Net Weight	75 kg
Blade Material	Nylon Composite
Compliance	CE, GMC, TUV

System Type	Recommended Use	Notes
Off-Grid Power	Remote Cabins, Farms, RVs	Requires compatible 120V controller
Hybrid Systems	Solar/Wind supplement	Ideal for winter/night generation
Industrial	Telecom Base Stations	High reliability in coastal areas

Mounting: This turbine requires a suitable mounting pole (not included). Professional installation is recommended.
Wiring: Uses a triple wire connection for 3-phase AC output. Must be connected to a 120V AC wind charge controller before reaching a battery bank or inverter system.

Is this a genuine original part?

This is a premium quality WTD-series aftermarket replacement part, manufactured to meet international standards (CE/TUV) for industrial and residential renewable energy use.

How do I know if it is compatible?

Verify that your charge controller is rated for 120V AC input. This turbine is a direct replacement for WTD3000-120 model wind generators.

What happens in extremely high wind speeds?

The WTD3000-120 is equipped with a mechanical tail furling system. When wind speeds exceed safe thresholds, the tail vane forces the turbine head to pivot away from the wind direction, naturally slowing the rotor to prevent structural or electrical damage.
