ADVANCED PERFORMANCE: Features integrated bypass diodes between every single cell, delivering up to 20% higher energy yield in partially shaded environments compared to conventional modules.

Key Features

• ✔ Ultra-Lightweight: Only 6.3kg, ideal for weight-sensitive roofs.
• ✔ Shatterproof: No glass construction; can be carefully walked on.
• ✔ Self-Adhesive: Peel-and-stick backing for tool-free installation.
• ✔ Aerodynamic: Discreet 2mm thickness reduces wind drag.

Technical Specs

Peak Power (Pmax)	270W
Max Power Voltage (Vmp)	41.5V
Max Power Current (Imp)	6.6A
Open Circuit Voltage (Voc)	50.7V
Short Circuit Current (Isc)	7.5A
Dimensions	1685 x 1298 x 2mm
Weight	6.3 kg

System/Vehicle	Recommended Use	Notes
Motorhomes & Caravans	Curved roof mounting	Eliminates drilling into the shell.
Marine / Boats	Deck or cabin top	Saltwater resistant & shatterproof.
Off-Grid Roofing	Bitumen or membrane roofs	Follows the shape of the structure.

1. Ensure the mounting surface is clean, dry, and free of grease.
2. Test position the panel before removing the adhesive backing.
3. Gradually peel and press from one end to avoid air bubbles.
4. Connect to an appropriate MPPT charge controller (recommended due to high Vmp).

Is this a genuine Solarika part?

This is a premium quality Solarika branded CIGS module, manufactured to international standards (TÜV certified) for superior performance in mobile and residential environments.

How do I know if it is compatible with my system?

The SELM8-270 has an Open Circuit Voltage of 50.7V. Ensure your charge controller is rated for at least 60V-75V input to handle cold-weather voltage spikes.

Can this panel be walked on?

Yes. Because CIGS technology does not use a glass top layer and is shatterproof, the panel can be carefully walked on with soft-soled shoes during maintenance, provided it is mounted on a solid, flat surface.
